HUNKELER HPF-660

Technical data HPF-660 - Paper web width: Min. 178 mm; Max. 520 mm - Mechanical speed: Min. 10 m/min; Max. 200 m/min; Set-up mode 5 m/min - Production - Speed: With flying folder max. 100 m/min; With flying folder module 100 m/min - Drive power: DCU 075 7.5 KW DCU 150 15.0 KW - Back-up fuse: DCU 075 max. 80A, 50/60 Hz DCU 150 max. 100A, 50/60 HZ - Temp. range workshop hall 10 - 25° Equipment: Paper unwinding station RUM 660 insetter INF 660 - consisting of print mark reader, web edge control and web infeed device with register control. DM 660 die-cutting module Magnetic die-cutting cylinder with: - suction unit for die-cutting cut-outs AM 660 application module - with lateral roll unwinding for register-controlled application of unprinted webs, labels, silicone paper, foils, etc. minimum dispensing length 1 inch - format set 24 inch pitch for format 4" / 6" / 8" / 12" - format set 20 inch pitch for format 6 2/3" / 5" / 10" Turning module WTM 660 - for turning the paper web by 180° while maintaining the running direction Glue module_GM-V 660 - for partial gluing of the paper web with dispersion glue - 2 plow folding stations for one-sided or double-sided longitudinal folding of the paper web with longitudinal cutting device and longitudinal perforation - device for longitudinal creasing Cross perforating module CPM 660 - Punch insert 24 inch Cross cutting module CM 660 - with pull-out belt and cross cutting cylinder - Formats: 32 inch pitch 8" - 16" 28 inch pitch 4 2/3" - 7" - 9 1/3" - 14" 25 inch pitch 4 1/6" - 8 1/3" - 12 1/2" 24 inch pitch all 2 inch pitch possible 6"- 12" 20 inch pitch 5 - 6 2/3" - 10" - Sheet delivery Star wheel system for formats 5" / 6" / 6 2/3" / 12" Hot glue from Reuther / HHS / Beckhoff C-1001 2x glue nozzles systems HM 200 B22 Special equipment: Invested for DHL parcel label, DIN A4 with back gluing, wrap fold 2x label dispenser from ETI Pack Energy 100 *All information without guarantee!
